Advantages
Specifications
Four column type
| Unit | DFM0806/50S | DFM1007/75S | DFM1310/100S | |
| Max. pressing capacity | ton | 50 | 75 | 100 |
| Max. lifting capacity | ton | 22 | 22 | 35 |
| Daylight opening | mm | 800 | 950 | 1200 |
| Worktable size | mm | 800x600 | 1000x750 | 1380x1000 |
| Adaptor reversing capacity | ton | 0.75 | 1.5 | 2 |
| Bolster loading capacity | ton | 1.5 | 3 | 5.5 |
| Fast ascending/ Descending speed | mm/sec | 85 | 75 | 75 |
| Slow ascending/ Descending speed | mm/sec | 20 | 20 | 25 |
| Main motor power | kW | 7.5 | 11 | 11 |
| Oil tank capacity | L | 300 | 380 | 900 |
Design & specifications are subject to change without prior notice!
Accessories
| DFM Four column type | |
| Hydraulic power system |  |
| Lubricating system | |
| Working light | |
| Safety bar | |
| Adjusting tools | |
| Digital device | |
| Hydraulic and pneumatic adapter | |
| Leveling screws and leveling wedges | |
Design & specifications are subject to change without prior notice!Application Case
